GigE Camera | HC-CS020-10GC 2.0 MP 1/1.7'' Mono CMOS GigE Area Scan Camera
- group name
- CS Series Area Scan Cameras
- Min Order
- 1 piece
- brand name
- MSTAR Machine Vision System
- model
- HC-CS020-10GC
- Nearest port for product export
- Shanghai, Ningbo
- Delivery clauses under the trade mode
- EXW
- Acceptable payment methods
- T/T
- update time
- Tue, 11 Jun 2024 17:11:44 GMT
Paramtents
Sensor type CMOS, global shutter
Sensor IMX430
Pixel size 4.5 µm
Sensor size 1/1.7"
Resolution 1624×1240
Max. Frame Rate 60fps
Mono/Color Color
Data Interface GigE
Lens mount C-Mount
Dimension 29 mm × 29 mm × 42 mm
Compatibility GigE Vision V1.2, GenICam
Packging & Delivery
- 20cm x10cm x10cm
-
Min Order1 piece
Briefing
IMX430 Image Sensor 2.0 MP 1/1.7" Color CMOS 60 fps GigE Area Scan Camera
Detailed
GigE Camera | HC-CS020-10GC 2.0 MP 1/1.7" Color CMOS GigE Area Scan Camera
Specification
|
Model
|
HC-CS020-10GC
|
|
Sensor type
|
CMOS, global shutter
|
|
Sensor model
|
Sony IMX430
|
|
Pixel size
|
4.5 μm × 4.5 μm
|
|
Sensor size
|
1/1.7''
|
Resolution | 1624×1240 |
Max. frame rate | 60 fps |
Mono/color | Color |
Data interface | GigE |
Lens mount | C-Mount |
Dimension | 29 mm × 29 mm × 42 mm |
Weight | Approx. 100 g |
Compatibility | GigE Vision V2.0,GenICam |
Dimension
Applications
Electronics
Home Appliances
Electrical
